SPECIFICATION

Brand	Merida
Fork	RockShox Judy TK; Coil; 100mm travel. Lockout; 46mm offset. Max. tyre size: 29″ x 2.25″
Head Set	Merida M2345
Stem	Merida CC; aluminium; 31.8mm diameter; 6 degree rise – Stem length: 70mm (XS/S), 80mm (M), 90mm (L)
Handle Bars	Merida CC; aluminium; 690mm wide; 15mm rise
Tape Grips	Merida EC
Brakes	Tektro HD-M275; 2 piston hydraulic disc brake caliper with Shimano RT10; 160mm rotor
Brake Levers	Tektro HD-M275
Rear Derailleur	Shimano Deore M6100SGS Shadow+
Shift Levers	Shimano Deore SL-M6100 12 speed
Cassette	KMC X12
Chainset	Shimano Deore M6100; 30 tooth chainset. Crank length: 170mm (XS,S), 175mm (M,L)
Pedals	Yes
Wheels	Merida CC; 17mm inner rim width; Aluminium
Front Tyre	Merida K1080; 29″ x 2.2″; wire bead
Rear Tyre	Merida K1080; 29″ x 2.2″; wire bead
Saddle	Merida Sport comfort
Seat Post	Merida Comp CC; aluminium; 30.9mm diameter; in-line
Material	Aluminium
