Description

SPECIFICATION

Brand	Merida
Frame	Lite II – 6066 triple butted hydroformed aluminium. Internal cable routing. Tapered head tube, inboard disc mount, BSA BB standard, 135 x 9mm QR axle. Mounts for rack, mudguards and kickstand. Max. tyre size 700 x 35c (700 x 32c with mudguard)
Fork	Speeder CF2; Full carbon, tapered steerer, 100 x 9mm QR standard, Max. tyre size: 700 x 35c (700 x 32c with mudguard)
Head Set	Merida M2331 Neck
Stem	Merida Comp CC; aluminium; 31.8mm diameter; 6 degree rise – Stem length: 80mm (XS), 90mm (S), 100mm (SM/ML), 110mm (L/XL)
Handle Bars	Merida Comp TK; aluminium; 600mm wide; Flat
Tape Grips	Merida Comp EC
Brakes	Tektro HD-M275; 2 piston hydraulic disc brake caliper with Shimano RT10; 160 mm rotor
Brake Levers	Tektro HD-M275
Rear Derailleur	Shimano Sora; SS
Rear Hub	Shimano TX505; 135x9mm; 32 spokes; Center lock; Quick Release
Front Hub	Joytech D471SBT-SC-CL; 100x9mm; 28 spokes; Center lock; Quick Release
Shift Levers	Shimano SL-R3000
Cassette	KMC M99
Chainset	FSA Tempo; 50-34 tooth chainset. Crank length: 170mm (XS,S/M), 175mm (L,XL)
Pedals	VP Components, VPE-891
Wheels	Merida Comp SL; 17mm inner rim width; 22mm depth; Aluminium
Front Tyre	Maxxis Detonator; 700 x 32C; wire bead
Rear Tyre	Maxxis Detonator; 700 x 32C; wire bead
Saddle	Merida Comp SL; V-mount
Seat Post	Merida Comp CC; aluminium; 30.9mm diameter; 5mm lay back
Material	Aluminium

Select a size	50 cm, 54 cm, 56 cm
Select a colour	Red
